JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3ļ¼103
3
3.8.7 Set User Option Keys [OPTION 1/2]
Users can freely make settings with [OPTION 1] key and [OPTION 2] key.
By using the keys, users can open a frequently used menu by only single
operation, or assign special functions, to the user key switches.
3.8.7.1 Initial Setting (Option Key Setting)
Set functions that can be performed with the option key switches.
Procedures
1) Open the Option Key Setting menu by performing the menu
operation below.
→
→
The Option Key Setting menu will appear.
This system provides two user keys: [OPTION 1] and [OPTION 2]. Different functions can
be allocated to each key.
Functions that can be allocated to each key are as follows:
: A specific menu is directly displayed.
: The zoom display function is switched between on and off.
: Set/Cancel Waypoint menu key
: Start-point, Pass-point key in simple route operating
: End-point key in simple route operating
: Screen capture key (This function is enabled only when the
card (optional) is connected.)
Main
7. Sub Menu
4. Option Key Setting
Menu
Zoom
DEST
->ā—‹
ā—‹->
Capture Screen
