JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3ļ¼105
3
3.8.8 Set Navigation Data Display (Multi Window Setting)
By performing the following operation, it is possible to display navigation data of
the wind direction / velocity, water depth and the like, as a graph on the radar
display.
Procedures
1) Open the Multi Window Setting menu by performing the menu
operation below.
āć
The Multi Window Setting menu will appear.
Detailed settings of the display are possible by changing the settings of each item.
3.8.8.1 DIR/DIST EXP Display
ā¢ Determine whether to expand the value display of cursor, EBL, and VRM.
ā¢ The value display is expanded in digital information area 2.
ā¢ When the cursor mark moves on the PPI, the display of cursor information is
expanded.
ā¢ When an EBL or VRM is operated, the value display of each marker is
expanded.
ā¢ While the menu is open, any display is not expanded.
3.8.8.2 Numeric NAV INFO
ā¢ Determine whether to display the numeric values of received navigation
information.
ā¢ One of two digital information areas is used to display data.
ā¢ When navigation data is displayed, the sizes of the target tracking (TT)/AIS
numeric data display areas are exclusively decreased.
: Does not expand any display.
: Expands the display in digital information area 2. The
expanded display remains for 5 seconds after the
operation of each marker, and then it will disappear.
: Expands the display in digital information area 2.
Main
4. Multi Window Setting
Off
On
Always On
To Next Page
