JMA-9100 Instruction Manual > 8.COUNTERMEASURE FOR TROUBLE ... > 8.4 REPLACEMENT OF MAJOR PARTS
8.4.1 Parts Required for Periodic Replacement
Here are parts required for periodic replacement
8.4.2 Replacement of magnetron
When mounting a new magnetron, do not touch the magnet with a screwdriver or
put it on an iron plate. After replacement, connect the lead wire correctly.
Handling of Magnetron under Long-Time Storage
The magnetron that has been kept in storage for a long time may cause sparks and
operate unstably when its operation is started. Perform the aging in the following
procedures:
1) Warm up the cathode for a longer time than usually. (20 to 30 minutes
in the STBY state.)
2) Start the operation from the short pulse range and shift it gradually to
the longer pulse ranges. If the operation becomes unstable such as
the magnetron current is unstable, in during this process, return it to
the standby mode immediately. Keep the state for 5 to 10 minutes until
the operation is restarted.
Part name Interval Radar model Part type Part code
1. Magnetron 4,000 hours
JMA-9110-6XA/6XAH
MAF1565N
i
i. Use a genuine magnetron.
5VMAA00102
JMA-9122-6XA/9XA/6XAH
JMA-9123-7XA/9XA
M1568BS
i
5VMAA00106
JMA-9132-SA
JMA-9133-SA
M1555
i
5VMAA00104
2. Motor 10,000 hours
JMA-9110-6XA/6XAH
H-7BDRD0048*
ii
ii. ā*ā means revision, such as A, B and so on.
7BDRD0048*
ii
JMA-9122-6XA/9XA
JMA-9123-7XA/9XA
MDBW10822*
ii
MDBW10822*
ii
JMA-9122-6XAH
H-7BDRD0045*
ii
7BDRD0045*
ii
JMA-9132-SA
JMA-9133-SA
MDBW10823*
ii
MDBW10823*
ii
3. Fan (Scanner Unit) 20,000 hours
JMA-9122-6XA/9XA/6XAH
JMA-9132-SA
H-7BFRD0002*
ii
7BFRD0002*
ii
4. LCD PANEL 50,000 hours
CML-799L CML-799L
5. Fan
(Radar Process Circuit)
20,000 hours
109R0612S4D13 5BFAB00588
(Power Supply)
20,000 hours
H-7BFRD0006*
ii
7BFRD0006*
ii
7. Backup battery 5 years
CR2032 5ZBCJ00012
Replacement of magnetron must be made by specialized
service personnel.
For details, refer to Service Manual.
Use genuine parts as mentioned above.
