JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.4 GENERAL RADAR OPERATION
3.4.14 Set True Bearing
When the GYRO I/F is used to enter a gyro signal, there is a rare case in which a
true bearing value indicated by the master gyro does not match the true bearing
value indicated by this radar system.
In that case, adjust the true bearing value of this system so that it matches the
value indicated by the master gyro.
Procedures
1) Open the numeric value input screen to enter a true bearing
value by performing the menu operation below.
āć
āć
2) Enter a value indicated by the master gyro on the numeric value
input screen.
For how to input numeric data on the numeric value input screen, see Section
3.3.4 "Operation on Numeric Value, Latitude / Longitude and Character Input
menu".
3.4.15 Set Own Ship Speed
3.4.15.1 Switch the own ship speed device
Procedures
1) Left-click the own ship speed device button in the Own Ship
Information area located at the upper right of the display.
The speed sensor is switched whenever the button is clicked.
(Manual) ā (Single-axis water log) ā (Dual-axis water log)
ć (GPS) ā (Dual-axis ground log)
Main
6.NAV Equipment Setting
1. Gyro Setting
MAN LOG
2AXW
GPS
2AXG
