JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.5 USE OWN SHIP'S TRACK
3ļ¼45
3
3.5.8 Use Water Temperature Track (Water TEMP Track)
Set the corresponding conditions for the water temperature value and the color of
own ship's track by performing the operation below.
Procedures
1) Open the Water TEMP. Setting menu by performing the menu
operation below
āć
The Water TEMP. Setting menu will appear.
Enter a value of the boundary water temperature for each item according to the table below
to set up the corresponding conditions for the water temperature value and the color of own
ship's track.
For example, if 10.0ā is entered for 1. , 13.0ā is entered for 2. , and 15.0ā is entered for
3. , the area with a water temperature of less than 10.0ā is indicated by white tracks, the
area with a water depth of 10.0ā to 13.0ā is indicated by gray tracks, and the area with a
water depth of 13.0 ā to 15.0 ā is indicated by blue tracks.
Water temperature
value
Color of track
White
1. xx.x ā
Min
Gray
2. xx.x ā
Blue
3. xx.x ā
Green
4. xx.x ā
Yellow
5. xx.x ā
Pink
6. xx.x ā
Max
Red
Track
7. Water TEMP. Setting
