JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.6 DISPLAY USER MAP
5) Left-click the button to input the latitude /
longitude.
For the input method on the latitude / longitude input screen, see Section 3.3.4.5 "Entering
latitude/longitude"
6) Left-click the button to input the comment.
For the input method on the character input screen, see Section 3.3.4.7 "Entering a character"
The window will not be open when the system is in the transmission state.
7) Left-click the button.
Mark / Line plotting will be terminated.
To create another mark or line, repeat procedures 4 to 7.
3.6.2 Set User Map Display (Mark Display Setting)
The user map can be individually displayed (On) or hidden (Off).
The mark font display size can be selected.
3.6.2.1 Setting display by type
Procedures
1) Open the Display Mark Type menu by performing the menu
operation below.
āć
āć
Setting by type: Setting can be made by mark font and line pattern.
Setting by color: Setting can be made by color of mark or line.
Normal: The mark is displayed in normal size.
Small: The mark is displayed in a size smaller than usual.
3. L/L
4. Comment
5. Enter
U.Map
5. Mark Display Setting
1. Display Mark Type
To Next Page
