JMA-9100 Instruction Manual > 6.TRUE AND FALSE ECHOES ON DISPLAY > 6.6 DISPLAY OF AIS-SART
6.6 DISPLAY OF AIS-SART
AAIS-SART is an equipment to display the position of distress ship on the AIS
indicator in ship station or coast station when the distress occurs.
It is usable as an alternate equipment of SART(Search And Rescue Transponder).
When connecting AIS indicator to RADAR, it is possible to display AIS-SART
symbol on the RADAR screen.
6.6.1 Display
When receiving AIS-SART signal, AIS-SART symbol is displayed on the
RADAR screen.
Fig 6-10: Example of AIS-SART Symbol display
For details of AIS-SART Symbol, refer to Section 5.1.2.2 "Types and Definitions
of AIS Target Symbols".
Land Area
Other
Ship
AIS-SART
Symbol
