JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.5 USE OWN SHIP'S TRACK
3.5.5 Clear Own Ship's Track (Clear Own Track)
This function cancels the storing of own ship's track.
Procedures
1) Open the Clear Own Track Color menu by performing the menu
operation below.
āć
The Clear Own Track Color menu will appear.
2) Left-click the button for the color to be deleted.
: All tracks are deleted
/ / / / / / :
Only track of specified color is deleted.
After the item has been selected, Clear Own Track Confirmation Window will appear.
3) Left-click the Yes button.
Own ship's track indicated by the specified color will be deleted.
3.5.6 Use Expanded Own Ship's Track (Own Track Type)
The following expanded track functions can be used for this radar system.
Only one type of expanded own ship's track can be used at a time. Multiple types
of expanded tracks cannot be used at the same time.
Specify the type of the expanded own ship's tracks to be used by performing the
operation below.
Water temperature track : The water temperature value at the latitude/longitude is
recorded.
Water depth track : The water depth value at the latitude/longitude is recorded.
Tidal current track : The tidal current vector at the latitude/longitude is recorded.
Track
2. Clear Own Track Color
All
White Gray Blue Red Pink Yellow Green
To Next Page
