JMA-9100 Instruction Manual > 11.SPECIFICATION > 11.9 SCANNER UNIT (NKE-1130)
11 ļ¼9
11
11.9 SCANNER UNIT (NKE-1130)
SCANNER UNIT怀NKE-1130
Dimension Height 791 x Swing Circle 4000 (mm)
Mass Approx.180kg
Polarization Horizontal
Directional Characteristics Horizontal beam width
Vertical beam width
Side lobe Level
: 1.9°
: 25°
: below -26dB (within +/-10°)
: below -30dB (outside +/-10°)
Revolution Approx.24rpm
Power Supply for Motor
AC100 - 115V态50/60Hz态1φ or
AC220 - 240V态50/60Hz态1φ
Maximum Wind Velocity 51.5m/s (100knots)
Transmitting Frequency
3050±20MHz
Transmitting Power 30kW
Transmitting Tube Magnetron[M1555]
TX Pulse width / Repetition
Frequency
SP1:0.07μs/2250Hz
MP1:0.2μs/2250Hz MP2:0.3μs/1900Hz态MP3:0.4μs/1400Hz
LP1:0.8μs/750Hz态LP2:1.0μs/650Hz LP3:1.2μs/510Hz
0.125态0.25态0.5NM :SP1
0.75NM
:SP1/MP1
1.5NM
:SP1/MP1/MP2/MP3
3NM
:MP1/MP2/MP3/LP1
6NM
:MP1/MP2/MP3/LP1/LP2
12NM
:MP1/MP2/MP3/LP1/LP2
24NM
:MP3/LP1/LP2
48NM
:LP2
96NM
:LP3
Modulator Solid State Modulator Circuit
Duplexer Circulator + Diode Limiter
Front End Module Built-in
Intermediate Frequency Amplifier Intermediate Frequency
Band Width
Gain
Amplifying Characteristics
: 60MHz
: 25/8/3MHz
: more than 90dB
: Logarithmic Amplifier
Overall Noise Figure 7.5dB ( Typical)
Tuning Manual/AUTO
