JMA-9100 Instruction Manual > 1.GENERAL AND EQUIPMENT COMPOSITION > 1.3 CONFIGURATION
1.3 CONFIGURATION
※The class of emission: P0N (All scanner types)
Table1-1:Specified of scanner, and categories of ship/craft for SOLAS V
Type of Radar Antenna type Transmitted
Output Power
Band Rate of
rotation
Category
JMA-9133-SA 12ft Slotted Antenna 30kW S 24rpm CAT 1
JMA-9132-SA 12ft Slotted Antenna 30kW S 24rpm CAT 1
JMA-9123-7XA 7ft Slotted Antenna 25kW X 24rpm CAT 1
JMA-9123-9XA 9ft Slotted Antenna 25kW X 24rpm CAT 1
JMA-9122-6XA 6ft Slotted Antenna 25kW X 24rpm CAT 1
JMA-9122-9XA 9ft Slotted Antenna 25kW X 24rpm CAT 1
JMA-9122-6XAH 6ft Slotted Antenna 25kW X 48rpm CAT 1H
JMA-9110-6XA 6ft Slotted Antenna 10kW X 27rpm CAT 1
JMA-9110-6XAH 6ft Slotted Antenna 10kW X 48rpm CAT 1H
Table1-2:Radar Configuration and Ship's Mains
Type of Radar Scanner Unit
Performance
Monitor
Transmitter
Receiver
Unit
Display
Unit
Ship’s Main
JMA-9133-SA NKE-1139 NJU-84 NTG-3230 NCD-4990
AC100 to 115V, or
AC220 to 240V 50/60Hz
1φ
JMA-9132-SA NKE-1130 NJU-84
―――
NCD-4990
JMA-9123-7XA NKE-1129-7 NJU-85 NTG-3225 NCD-4990
JMA-9123-9XA NKE-1129-9 NJU-85 NTG-3225 NCD-4990
JMA-9122-6XA NKE-1125-6 NJU-85
―――
NCD-4990
JMA-9122-9XA NKE-1125-9 NJU-85
―――
NCD-4990
JMA-9122-6XAH NKE-2254-6HS NJU-85
―――
NCD-4990
AC100 to 115V, or
AC220 to 240V 50/60Hz
1φ
JMA-9110-6XA NKE-2103-6 NJU-85
―――
NCD-4990
JMA-9110-6XAH NKE-2103-6HS NJU-85
―――
NCD-4990
