JMA-9100 Instruction Manual > 1.GENERAL AND EQUIPMENT COMPOSITION > 1.3 CONFIGURATION
1ļ¼5
1
Notes:
1) The drive motor for the scanner unit is available in AC100-115V
or AC220-240V type for NKE-1139/1130/1125/1129 series. Please
specify the motor type when ordering.
2) The motor of NKE-2254/2103 can operate under both AC100-115V
and AC220-240V, then need not to specify the motor type.
3) When using NKE-2254/2103, they need AC/DC Converter NBA-
5135 (Option) in display unit.
4) The scanner unit except NKE-2103 series can be equipped with a
deicing heater as an option, and '-D' shall be suffixed to the type
name. (e.g. NKE-1139-D, NKE-1125-6D).
5) When using the ship's mains of AC440V as the radar power
source, a step-down transformer shall be used.
6) The desktop option is available for display NCD-4990. It has a
separate structure consisting of the following:
7) In JMA-9123, the following type name of JRC is used for the
flexible wave guide between the scanner unit and the transmitter
receiver unit.
8) In JMA-9133, the following type name of JRC is used for the
coaxial cable between the scanner unit and the transmitter
receiver unit.
Monitor Unit NWZ-170
Radar Process Unit NDC-1399-9
Operation Unit NCE-5163
Type of Radar Waveguide Length(m) Type name of JRC
JMA-9123-7XA/9XA FR-9 20MT H-7AWRD0003
JMA-9123-7XA/9XA FR-9 30MT H-7AWRD0004
Type of Radar COAX cable Length(m) Type name of JRC
JMA-9133-SA HF-20D 30MT HF-20D (30MT)
