JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.4 GENERAL RADAR OPERATION
3.4.4 Use Video Processing (PROC)
This function reduces unnecessary noise to highlight targets.
Procedures
1) Left-click the PROC button located at the lower left of the
display.
The video processing modes are switched.
ā ā
ā ā
ā¢ When viewing a radar beacon, SART signal, or fast
moving target on the radar display, select
(video process off).
ā¢ If video processing mode is set to CORREL , it may
be difficult to detect high speed target.
Video process modes
: Select this mode in general.
: Select this mode when many rain/snow clutter returns are detected.
: Select this mode to highlight targets while suppressing sea clutter
returns.
: Select this mode to detect small targets hidden by sea clutter
returns.
: Select this mode when own ship yaws wildly.
: Select this mode to detect small targets of which detection
probability is low.
Attentio n
PROC Off
PROC Off 3Scan CORREL 4Scan CORREL
Peak Hold Remain 5Scan CORREL
PROC Off
3Scan CORREL
4Scan CORREL
5Scan CORREL
Remain
Peak Hold
