JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.5 USE OWN SHIP'S TRACK
3.5.9 Use Tidal Current Track (Current Vector Track)
Set the conditions for adding tidal current vectors to own ship's track by
performing the operation below.
Procedures
1) Open the Current Setting menu by performing the menu
operation below.
→
The Current Setting menu will appear.
Set the tidal current vector display conditions.
[1]Length of the tidal current vector (Current Size)
• Set the length of the tidal current vector.
• The unit of measure is kn/cm.
• If 1.0kn/cm is set, a tidal current of 1.0kn is shown as a one-centimeter line
on the radar display.
[2]Color of the vector for tidal current layer A (Layer A)
• Set the vector's display color for tidal current layer A.
• Choose one of the following colors
White态Gray态Blue态Green态Yellow态Pink态Red
[3]Color of the vector for tidal current layer B (Layer B)
• Set the vector's display color for tidal current layer B.
• Choose one of the following colors
White态Gray态Blue态Green态Yellow态Pink态Red
[4]Color of the vector for tidal current layer C (Layer C)
• Set the vector's display color for tidal current layer C.
• Choose one of the following colors
White态Gray态Blue态Green态Yellow态Pink态Red
Track
8. Current Setting
