JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3ļ¼95
3
3.8.2 Set Radar Trails (RADAR Trails Setting)
This function enables the setting of detail information about radar trails
processing.
Procedures
1) Open the RADAR Trails Setting menu by performing the menu
operation below.
āć
āć
The RADAR Trails Setting menu will appear.
Detail data about radar trails processing can be set by changing the settings of each menu
item.
3.8.2.1 Trails Mode
ā¢ Set the radar trail display mode.
ā¢ For details on the trail mode, see Section 3.4.8 "Display Radar Trails (Trails)"
3.8.2.2 Trails Reference Level
ā¢ Select a radar video level required for plotting radar trails.
ā¢ The radar video threshold level increases in order of ā
ā ā .
ā¢ To plot radar trails with unwanted waves, change to a higher level.
ā¢ To thin radar trails, change to a higher level.
ā¢ If radar trails are plotted in snatches, change to a lower level.
NOTE:
After the settings for radar trails processing are changed,
targetsā trails may not be displayed or trails may be plotted with
unwanted waves. Thus, do not make a significant change in the
settings.
Main
3. RADAR Menu
2. RADAR Trails Setting
Level1 Level2
Level3 Level4
To Next Page
