3.6.6 Set and Display Geodetic System (Geodetic)
To create navigation information, set the geodetic system that is used with the
connected navigation equipment. When navigation information is loaded, the
geodetic system used when the navigation information was saved, is displayed.
Make sure that the displayed geodetic system is identical to the one used with the
navigation equipment. If the two geodetic systems are different, the positions of
navigation information on the radar display will be shifted. Therefore, it is
important to set the geodetic system of the navigation equipment.
[1] Setting the geodetic system for navigation data to be saved (Geodetic)
Procedures
1) Open the Geodetic menu by performing the following menu
operation.
āć
The numeric value input screen for Geodetic will appear.
2) Enter the desired geodetic system number.
The geodetic system is determined.
For how to input numeric datas on the numeric value input screen, see Section 3.3.4
"Operation on Numeric Value, Latitude / Longitude and Character Input menu".
[2] Displaying the geodetic system of the navigation data being displayed (Geodetic)
Procedures
1) Load navigation data by referring to Section 3.6.5.1 "Loading
navigation data (Load User Map)".
2) Open the Mark Operations menu by performing the following
menu operation.
The geodetic system will be displayed in the field.
U.Map
6. Geodetic
U.Map
6. Geodetic
