Page #158 background imageLoading...
Page #158 background image
3ļ¼38
JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.4 GENERAL RADAR OPERATION
2) Set whether to make corrections or not.
⇔
3) Input the correction value.
Press the or button to select south and north for latitude or the east and west
for longitude.
For how to input numeric data on the numeric value input screen, see Section 3.3.4
"Operation on Numeric Value, Latitude / Longitude and Character Input menu".
3.4.16.1 Set Drift Correction
The direction and speed of the drift are set.
This function can be used only when or is selected for ship-speed
data.
Procedures
1) Open the Set/Drift Setting menu by performing the menu
operation below.
→
→
2) Set whether to make corrections or not.
⇔
For menu operation, see Section 3.3.3 "Basic Menu Operation".
3) Enter the correction value for tidal current.
For how to input numeric data on the numeric value input screen, see Section 3.3.4
"Operation on Numeric Value, Latitude / Longitude and Character Input menu".
: Direction of tidal current (true bearing)
: Speed of tidal current
1. Heading Correction
Off
On
+
ļ¼
MAN LOG
Main
6.NAV Equipment Setting
3. Set/Drift Setting
1. Correction
Off
On
2.Set
3.Drift
