JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.8 APPLIED OPERATIONS
3ļ¼91
3
3.8 APPLIED OPERATIONS
3.8.1 Set Radar Signal Processing (Process Setting)
This function enables the setting of detail information about radar signal
processing.
Procedures
1) Open the Process Setting menu by performing the menu
operation below.
āć
āć
The Process Setting menu will appear.
Detail information about radar signal processing can be set by changing the settings of the
menu items.
3.8.1.1 Video Latitude
ā¢ Select the dynamic range in which receiving signals are to be shown on the
radar display.
ā¢ Select in standard, and in rainy weather.
ā¢ clearly displays short-range videos when STC is used in manual
mode.
NOTE:
After the settings for radar signal processing are
changed, small targets may not be displayed or
unwanted waves may not be suppressed. Thus, do not
make a significant change in the settings.
: Narrows the dynamic range at short range.
: Standard setting
The dynamic range varies depending on the actual range:
Short distance: wide Long distance: narrow
: Use this mode when rainy weather intensifies unwanted
waves.The dynamic range is about twice as wide as when
is selected.
: Use this mode when rain cloud remain at mode.
Main
3. RADAR Menu
1. Process Setting
Normal
Wide
Narrow
Narrow
Normal
Wide
Normal
Super Wide
Wide
To Next Page
