3.12 RECEIVE PORT SETTING
The system can receive data from other system via the JRC-LAN. The purpose of
JRC-LAN is interoperation with other JRC systems. The JRC systems are
synchronized with datum in JRC-LAN network.
3.12.1 Receive Port Setting (RX Port)
Select ports for receiving signals from sensors.
There are two methods for receiving signals: specifying a port for each sensor, or using
the automatic recognition function without specifying ports.
Procedures
1) Open the RX Port Setting menu by performing the menu
operation below.
→
→
2) Set a port for each sensor.
NOTE: If the connection is not suggested from JRC office, don't connect PC or other
maker's system to JRC-LAN.
•Connecting PC or other maker's system may cause a lower radar system performance.
•Connecting PC or other maker's system may cause a lower that performance.
Settable sensor signals
Heading, Speed, AIS, GPS, DLOG, Alarm, Depth, Temperature, Wind, Current, ROT, RSA, Time
Zone, Date/Time
Selectable ports
When the automatic recognition
function is used:
When ports are specified:
Behavior pattern of selectable ports
: Data from JRC-LAN is prior
:
The system use data from sensor connected to the system directly.
: The system uses data from JRC-LAN.
:
The system uses GPS data from GPS (JRC-LAN connected).
:
The system uses ship's clock data from ship's clock (JRC-LAN
connected)
Setting of Section 7.2.11.2 "Reception Port Setting (RX Port)" is prior. If you want to set this
menu, Section 7.2.11.2 "Reception Port Setting (RX Port)" menu set to .
Main
6. NAV Equipment Setting
6. RX Port
AUTO
Own LAN LAN (GPS) LAN (Ship’s Clock)
AUTO
Own
LAN
LAN (GPS)
LAN (Ship’s Clock)
i
User Setting
