JMA-9100 Instruction Manual > 5.OPERATION OF TARGET TRACKING AND AIS > 5.1 PREPARATION
5ļ¼11
5
5.1.4 Cursor Modes (Cursor)
5.1.4.1 Types and Functions of Cursor Modes
The types of cursor modes are listed in the table below. To use the function of a
cursor mode, move the cursor onto the PPI object and left-click.
5.1.4.2 Change of Cursor Mode
Procedures
1) Left-click the Cursor button located at the upper right of the
display. Alternatively, on the PPI, right-click and select a desired
cursor mode from the list.
The selected cursor mode will be shown at the cursor mode (Upper right of the display on
page 2-4).
Mode Function
ACQ TT Enables the target tracking function to acquire a target in manual
mode.
ACT AIS Activates AIS targets, and sets a point filter.
TGT Data Displays the numeric data of a tracking target or AIS target.
CNCL TT Cancels a tracking target.
DEACT AIS Deactivates AIS target.
Data CNCL Hides the displayed numeric data of a tracked target or AIS target.
Mark Puts a temporary mark.
Property Displays the information of tracked targets, AIS targets, and marks.
AUTO Changes operation in accordance with the object at the cursor
position.
If the function of a selected cursor mode is not used for one
minute or more, the cursor mode is automatically changed to
AUTO .
i
