JMA-9100 Instruction Manual > 11.SPECIFICATION > 11.3 JMA-9123-7XA/9XA TYPE RADAR
11 ļ¼3
11
11.3 JMA-9123-7XA/9XA TYPE RADAR
GENERAL SPECIFICATION
Class of emission P0N
Display Color Raster Scan
Screen 23.1inch LCD (Effective diameter of Radar: more than 320mm)
Range Scale 0.125, 0.25, 0.5, 0.75, 1.5, 3, 6, 12, 24, 48, 96NM
Range Resolution less than 30m
Minimum Detection Range less than 40m
Bearing Accuracy less than 1Ā°
Bearing Indication Relative motion mode : N-UP, C-UP and H-UP
True motion mode : N-UP and C-UP
Ambient Condition Temperature
SCANNER UNIT -25 to +55ā (Storage -25 to +70ā)
Other Unit -15 to +55ā
Relative humidity 93% at +40ā
Vibration
2 to 13.2Hzć Amplitude +/-1mm +/-10%
13.2 to 100HzćAcceleration 7m/s
2
Power Supply Input AC100 to 115V, 50/60Hz, 1Ļ or
AC220 to 240V, 50/60Hz, 1Ļ
Power Consumption Approx.350VA typical
Approx. 1700VA at Maximum wind speed
PS Voltage Fluctuation +/-10% (at the maximum cable length)
Pre Heating Time Within 4 minute
From STBY to TX Within 5 sec.
SCANNER UNIT (NKE-1129-7/9)
See 11.10
TRANSMITTER RECEIVER UNIT (NTG-3225)
See 11.16
DISPLAY UNIT (NCD-4990)
See 11.17
PERFORMANCE MONITOR (NJU-85)
See 11.21
OPTION
Scanner with Deicing Heater NKE-1129-7D/9D (Only heater collar)
Interswitch Unit NQE-3141-2A (Maximum 2 Radars)
NQE-3141-4A (Maximum 4 Radars)
DISPLAY UNIT (Desktop type) NCD-4990T
Maximum Cable Length
SCANNER UNIT to
TRANSMITTER RECEIVER UNIT
30m
DISPLAY UNIT to
TRANSMITTER RECEIVER UNIT
35m
SAFE DISTANCE FOR STANDARD COMPASS
SCANNER UNIT 1.05m
TRANSMITTER RECEIVER UNIT 2.8m
DISPLAY UNIT 4.0m
