JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.4 GENERAL RADAR OPERATION
3ļ¼29
3
3.4.7 Move Own Shipās Display Position (Off Center)
The own shipās position can be moved from the display center to any position
within 66% of the display radius. This function is convenient for observing a wide
coverage in any direction.
If Off Center functions set to scanner position is outside of the PPI range, when
function switching display with reference to scanner position.
Procedures
1) Left-click the Off Center button located at the upper left of the
display.
The cross cursor mark will appear at the own shipās position on the radar display.
2) Move the cross cursor mark (own shipās display position) to a
desired position by using the trackball.
While the cross cursor mark is moving, the own shipās display position moves following
the cross cursor mark.
When it moves to a position outside 66% of the display radius, the center position is limited
to a position within 66% of the display radius.
3) Press the trackball button on the left key.
The own shipās display position will be fixed to the cross cursor mark.
3.4.7.1 Returning Own Ship's Position to the Center
Procedures
1) Left-click the Off Center button for 2 seconds.
The own ship position is returned to the center of the display.
This function is not available on the 96 NM range.
i
Move the cursor mark to
a desired position
HL
Press the [
ENT]
key
The own shipās display
To Next Page
