JMA-9100 Instruction Manual > A.NQE-3141 Interswitch Unit > A.2 INTERSWITCH OPERATION
A.2.5 Operating Connection Pattern Files (File Operations)
Frequently used connection patterns can be read easily by saving interswitch
connection patterns.
[1] Loading connection patterns (Load)
Procedures
1) Open the Inter Switch Menu (with 3 or More Display Units).
2) Left-click the button.
The File Operations menu will appear.
3) Left-click the button.
Currently saved connection patterns in memory will be listed.
4) Left-click the button corresponding to the file to be loaded.
Confirmation Window will appear.
5) Left-click the to load.
The connection pattern will be changed.
[2] Saving connection patterns (Save)
Procedures
1) Open the Inter Switch Menu (with 3 or More Display Units).
2) Left-click the button.
The File Operations window will appear.
3) Left-click the button.
The Save menu will appear.
Currently saved connection patterns in memory will be listed.
4) Left-click the button corresponding to the file to be saved.
The Input File Name window will appear.
5) Enter the file name to be saved.
Up to 8 characters can be entered.For the input method on the character input screen, see
Section 3.3.4.7 "Entering a character".
The connection pattern will be saved when the name is input.
2. File Operation
3. Load
1. Yes
2. File Operation
2. Save
