JMA-9100 Instruction Manual > 4.MEASUREMENT OF RANGE AND BEARING > 4.1 USE OF NAVIGATION TOOLS
4.1.5 Operating EBL Maneuver Function (EBL Maneuver Setting)
4.1.5.1 Initial Setting (EBL Maneuver Setting)
Procedures
1) Open the EBL Maneuver Setting menu by performing the
following menu operation.
ćć āć
2) Set the following parameters.
For inputs to the value input screen, refer to Section 3.3.4 "Operation on Numeric Value,
Latitude / Longitude and Character Input menu".
:Set the range from when the rudder is steered to when
the ship beings to turn.
:Select a turn mode.
ć
:Turning radius (NM)
ć
:Rate of turn (deg/min)
:Select the setting for turning.
If is selected :Turning radius (NM)
If is selected :Rate of turn (deg/min)
i
A wrong initial setting affects the maneuver curve function
explained below.
Main
1. EBL Maneuver Setting
Reach
Turn Mode
Radius
Rate
Turn Set
Radius
Rate
To Next Page
