JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.5 USE OWN SHIP'S TRACK
3ļ¼43
3
Procedures
1) Left-click the button located at the lower right of the
display.
The Own Track Menu will appear.
2) Left-click the item button of .
The numeric value of the navigation data can be shown by the color of own ship's track.
3) Select the function to be used.
4) Left-click the item button of
Numeric value or vector of navigation data can be added to own ship's track.
5) Select the function to be used.
: The expanded own ship's track function is not used.
: The color of the tracks is changed according to the water
depth value
:The color of the tracks is changed according to the water
temperature value.
: Numeric value and vector are not added.
: Water depth value is added.
: Water temperature value is added.
:current vector is added.
NOTE:
To use the expanded own ship's track function, the track
must be entered from the special navigation equipment
into this radar system.
Track
Track menu
3. Track Type
Normal
Depth
Temperature
4. Num Vector Display
Off
Depth
Temperature
Current
To Next Page
