JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.6 DISPLAY USER MAP
3ļ¼49
3
5) Move the cursor to a desired location on the radar display and
left-click.
A line is plotted between the previous point and the end point. Repeat this procedure so that
sequential lines can be plotted.
6) When you want to finish plotting the line, left-click at the
previous point.
Line plotting will be terminated. To plot another line, repeat procedures 3.
3.6.1.3 Plotting a mark / line make with latitude and longitude
Procedures
1) Open the Edit User Map menu by performing the following menu
operation.
āć
āć
2) Left-click the button.
The Mark Input menu and the Line Input menu are switched.
3) Left-click the item button of to select the type of
mark font or line pattern to be created.
The desired mark font or line pattern is selected.
To add a line, select midpoint --O-- .
4) Left-click the item button of to select the color of
mark or line to be created.
The desired mark or line color is selected.
U.Map
2. Edit User Map
2. Make with L/L
9. New Mark Input
1. Type
2. Color
To Next Page
