3ļ¼48
JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.6 DISPLAY USER MAP
2) Left-click the mark font button to select a font for the
mark.
The mark fonts are switched.
3) Left-click the button located to the right of the mark font to
select a color for the mark.
The color for the mark font located to the right of the button will
change.
4) Left-click at a desired location on the radar display.
The specified mark will be displayed in the specified color.
To create another mark, repeat the above procedures.
3.6.1.2 Plotting a line
Procedures
1) Left-click the button located at the upper right
of the display to select the line mode.
The line pattern to be used is displayed to the right of the button.
2) Left-click the button located at the upper right of the
display to select the line pattern.
The line pattern to be used is displayed to the right of the button.
3) Left-click the button located to the right of the line pattern to
select a color for the line.
The color for the line pattern located to the right of the button will
change.
4) Left-click at a desired location on the radar display.
Line colors are switched.
ā”
C
Cursor
Cursor
Cursor
-------
Cursor
C
Cursor
