JMA-9100 Instruction Manual > 3.BASIC OPERATION > 3.7 USE ROUTE FUNCTION
3.7.3.6 Deleting a Waypoint (DEL)
The specified Waypoint in the route data saved in the radar system is deleted.
Procedures
1) Open the Waipoint Input menu.
2) Left-click the Waypoint Scroll button.
Left-click to show the desired waypoint.
3) Left-click the button to be corrected.
Confirmation Window will appear.
4) Left-click the button.
The specified Waypoint is deleted, and the previous and following Waypoints are then
connected by a line.
3.7.3.7 Inserting a Waypoint (INS)
A Waypoint is inserted at a specific location of the route data saved in the radar system.
Procedures
1) Open the Waipoint Input menu.
2) Left-click the Waypoint Scroll button.
Left-click to show the desired waypoint.
3) Left-click the button to be corrected.
The new latitude of waypoint is reversed.
4) Enter a latitude / longitude and a planned speed.
A Waypoint will be inserted.
For the input method on the latitude / longitude and numeric value input screen, see Section
3.3.4 "Operation on Numeric Value, Latitude / Longitude and Character Input menu".
DEL
1. Yes
INS
To Next Page
