3.8.5.2 Day/Night
• Specify the mode to be changed.
• The following modes are available:
Setting color of each element
• Specify the color for the element.
• The color for the following elements can be specified.
3.8.5.3 Setting display brilliance (Brilliance Setting)
For each Day/Night mode, background color outside the bearing scale,
background color inside the bearing scale, and color for characters, radar echo and
radar trails can be selected.
: Day mode 1 : Used under bright lighting conditions.
: Day mode 2 : Used under bright lighting conditions.
: Day mode 3 : Used under bright lighting conditions.
: Dusk mode : Used under dim lighting conditions.
: Night mode : Used under dark lighting conditions.
: The color of the background outside radar video PPI is
selected.
: The color of the background inside radar video PPI is
selected.
: The color of the character and bearing scale is selected.
: The color of the radar video is selected.
: The color of the time radar trails is selected.
: The color of the time radar trails is selected.
: The color of the target symbol is selected.
: The color of the cursor is selected.
: The color of the range rings is selected.
: The color of the EBL / VRM / PI is selected.
: The color of the own ship symbol, heading line, own
ship vector is selected.
i
Those selected color can be saved for each Day/Night mode.
Day1
Day2
Day3
Dusk
Night
Outer PPI
Inner PPI
Character
RADAR Video
RADAR Trails(Time)
RADAR Trails(All)
Target Symbol
Cursor
Range Rings
EBL/VRM/PI
Own Symbol /HL/Vector
