JMA-9100 Instruction Manual > 4.MEASUREMENT OF RANGE AND BEARING > 4.1 USE OF NAVIGATION TOOLS
4ļ¼11
4
[3] Control
Determines whether to operate all the lines at the same time. The setting items are
determined by the setting of Section [2] "Operation Mode".
a. If is selected
The setting cannot be changed.
b. If is selected
Determine whether to set consecutive lines or individual lines.
c. If or is selected
Select a group of lines to be operated.
[4] Floating
Moves the center point of parallel index lines.
[5] Heading Link
Determines whether to operate parallel index lines following the heading bearing.
:All the lines are operated at the same time.
:Lines are operated sequentially.
to :A specified line is operated.
to :A specified group is operated.
:The starting point of parallel index lines is defined as
the own ship's position.
:The center of parallel index lines is moved and fixed on
the radar display.
:The center of parallel index lines is moved and fixed at
the latitude and longitude. (The navigator needs to be
connected.)
:Parallel index lines are operated following the heading
bearing.
:Parallel index lines are not operated following the
heading bearing.
All
All
Individual
Sequential
Index Line1
Line8
Track
Equiangular
Group1
Group4
Off
Screen Fix
L/L Fix
On
Off
