JMA-9100 Instruction Manual > 7.SETTINGS FOR SYSTEM OPERATION > 7.2 SETTINGS
7－13
7
3) Set the baud rate of the port to be set.
7.2.1.2 Reception Port Setting(RX Port)
Set the numbers of ports for receiving signals from sensors.
There are two methods for receiving signals: specifying a port for each sensor, or
using the automatic recognition function without specifying ports.
Procedures
1) Open the Serviceman Menu.
2) Perform the following menu open procedure to open the RX Port
setting menu.
→
→
3) Set a port for each sensor.
1.
COMPASS
i
：
i. The compass port is a receive-only port that is dedicated to COMPASS signals.
4800(NMEA)/9600(NSK)/38400(fast NMEA)
ii
bps
ii. The bold values are factory-set.
2.
MAINTENANCE/LOG：
1200/4800/9600/38400 bps
3.
NAV1：
1200/4800/9600/38400 bps
4.
NAV2：
1200/4800/9600/38400 bps
5.
ALARM：
1200/4800/9600/38400 bps
6.
JARPA
iii
：
iii. The JARPA port is a transmit-only port that is dedicated to JRC ARPA signals.
1200/4800/9600/38400 bps
7.
AIS：
1200/4800/9600/38400 bps
8.
ARPA
iv
：
iv. The ARPA port is a transmit-only port.
1200/4800/9600/38400 bps
9.
COM
v
：
v. The COM port connector is D-sub 9pin.
1200/4800/9600/38400/115200 bps
Settable sensor
signals
GPS、DLOG、Alarm、Depth、Temperature、Wind、Current、
ROT、RSA
Selectable ports When the automatic recognition
function is used:
AUTO
When ports are specified:
LOG、NAV1、NAV2、
ALARM、COM
2. Installation Menu
5. COM Port Setting
2. RX Port
