JRC JMA-9110-6XA User Manual

9－2
JMA-9100 Instruction Manual > 9.TROUBLE SHOOTING AND AFTER-SALES SERVICE > 9.1 FAULT FINDING
Table9-2： List of System Error Message
Message Class Description
ALR No.
i
Autopilot (Data) Alarm Autopilot: No communication or data error. 101
Current (Data)
Alarm Tidal current: No communication or data error. 119
Date (Data)
Alarm Date data: No communication or data error. 112
Datum (Data)
Alarm DTM: No communication or data error. 122
Depth (Data)
Alarm Water depth: No communication or data error. 115
Fan (LCD)
Alarm LCD monitor: Fan error. 955
Fan (Power)
Alarm Power Supply: Fan error. 953
Fan (PROC)
Alarm RADAR Process Unit Interconnection: Fan error. 951
GPS (Status)
Alarm GPS status error. 103
GYRO I/F (Data)
Alarm GYRO I/F: No communication or checksum error. 324
GYRO I/F (GYRO)
Alarm GYRO I/F: GYRO error detected. 110
GYRO I/F (Log)
Alarm GYRO I/F: Log error detected. 111
Heading (Data)
Alarm Heading data: No communication or data error. 113
Keyboard (Data)
Alarm Operation unit: Communication error or checksum
error.
325
Keyboard2 (Data)
Alarm Second operation unit: Communication error or
checksum error.
325
Out of Bounds
Alarm
Own ship's latitude is over 85°N or 85°S.
123
Position (Data)
Alarm Latitude / longitude data: No communication or data
error.
102
PROC (AZI)
Alarm Process unit: AZI error. 305
PROC (HL)
Alarm Process unit: HL error. 306
PROC (Interrupt)
Alarm Process unit: Interrupt error. 962
PROC (Trigger)
Alarm Process unit: Trigger error. 304
PROC (Video)
Alarm Process unit: VIDEO error. 303
ROT (Data)
Alarm Rate of Turn: No communication or data error. 120
RSA (Data)
Alarm Rudder Sensor Angle: No communication or data
error.
121
Speed (2AXG)
Alarm 2-axis log (speed over ground): No communication
or data error.
114
Speed (2AXW)
Alarm 2-axis log (speed over water): No communication or
data error.
114
Speed (GPS)
Alarm GPS speed: No communication or data error. 114
Speed (Log)
Alarm 1-axis log: No communication or data error. 114
SRB (Data)
Alarm SRB: No communication or data error. 960
TEMP. (Data)
Alarm Water temperature: No communication or data error. 117
TXRX (AZI)
Alarm Scanner: BP error. 311
TXRX (Data)
Alarm Scanner: No communication, communication
mismatched, checksum error, or collision.
326
TXRX (Fan 1)
Alarm Scanner: FAN 1 error. 320
TXRX (Fan 2)
Alarm Scanner: FAN 2 error. 320
TXRX (Heater)
Alarm Scanner: Magnetron heater voltage error. 314
TXRX (HL)
Alarm Scanner: HL error. 312
TXRX (MHV)
Alarm Scanner: Modulator's high voltage alarm. 315
TXRX (Reverse)
Alarm Scanner: Reverse rotation. 313
TXRX (SSW Off)
Alarm Scanner: Safety switch OFF. 308
