JMA-9100 Instruction Manual > 11.SPECIFICATION > 11.17 DISPLAY UNIT (NCD-4990)
11 ļ¼19
11
Heading data HDT,THS
External alarm Default setting normally closed contact
Maximum current
200mA (SYSALM, ALPAALM, PWRALM
port at terminal board TB4601)
Acknowledge Contact output (ACKOUT port at terminal board TB4401)
Watchman reset Contact output (WMRST port at terminal board TB4401)
Remote maintenance
JRC format (MNT port at terminal board TB4601)
AIS alarm acknowledge
ACK (AIS port at terminal board TB4601)
External monitor
Multi scan monitor
Analog RGB, HD15pin Connector 2 port
i. Only with Navigation Equipment is connected.
ii. The Speed measuring accuracy of speed sensor shall confirm to IMO Resolution MSC.96(72).
The measuring accuracy of GPS shall confirm to IMO Resolution MSC.112(73).
iii. Can't be use for target tracking.
