Juniper MX104 Hardware Guide

NOTE: The output signals are not supported
Table 65: TOD Cable Specifications
ValueSpecification
RS-232 (EIA-232) serial cableCable specification
One 6-ft (1.83-m) length with RJ-45 connectorsCable/wire
6 ft (1.83 m)Maximum length
RJ-45 femaleConnector
Port Pinouts
Table 66 on page 91 provides the pinout information for the RS-232 connector for the
ToD port.
Table 66: ToD Port Connector Pinouts
DirectionDescriptionPin
–Reserved1
–Reserved2
OutputTransmit Data3
–Signal Ground4
–Signal Ground5
InputReceive Data6
–Reserved7
–Reserved8
Related
Documentation
• MX104 3D Universal Edge Router Overview on page 3
• MX104 Chassis Overview on page 4
• MX104 LEDs Overview on page 11
• MX104 Clocking and Timing Ports Overview on page 17
91Copyright © 2017, Juniper Networks, Inc.
Chapter 9: Port Cable and Pinout Specifications

Juniper MX104 Specifications

General

Product Name	MX104
Product Series	MX Series
Switching Capacity	80 Gbps
Throughput	80 Gbps
Operating System	Junos OS
Humidity	5% to 90% non-condensing
Interfaces	10 Gigabit Ethernet, Gigabit Ethernet
Power Supply	Dual redundant AC or DC
Cooling	Front-to-back airflow
Memory	8 GB
Operating Temperature	0°C to 40°C
