MIC LEDs
Each front-pluggable MIC has LEDs located on the faceplate. For more information about
LEDs on the MIC faceplate, see the “LEDs” section for each MIC in the MX Series Interface
Module Reference.
The built-in 10-Gigabit Ethernet MIC labeled XE accepts 10-Gigabit Ethernet SFP+. Each
transceiver has one pair of port LEDs. Table 44 on page 49 describes the LEDs in more
detail.
Table 44: SFP+ Port LEDs
DescriptionStateColorLocationName
The port is receiving data.BlinkingGreenLeftActivity
The port is not receiving data.Off–
Link is online.OnYellowRightLink
No link.Off–
Related
Documentation
MX104 Port and Interface Numbering on page 53•
• Replacing an MX104 MIC on page 161
• Maintaining the MX104 MICs and Network Ports on page 192
MICs Supported by MX Series Routers
The following tables list the first supported Junos OS release for the MX Series.
•
Table 45 on page 49 lists the first supported Junos OS release for MICs on MX240,
MX480, MX960, MX2008, MX2010, and MX2020 routers.
•
Table 46 on page 52 lists the first supported Junos OS release for MICs on MX5, MX10,
MX40, MX80, and MX104 routers.
Table 45:MICs SupportedbyMX240,MX480, MX960, MX2008, MX2010, and MX2020 Routers
MX2020
Routers
MX2010
Routers
MX2008
Routers
MX240,
MX480,
and
MX960
RoutersPortsMIC Model NumberMIC Name
ATM
12.312.315.1F712.18MIC-3D-8OC3-2OC12-ATMATM MIC with SFP
DS3/E3
