MX104 Router Physical Specifications
The MX104 router is a rigid sheet-metal structure that houses the hardware components.
Table 51 on page 69 summarizes the physical specifications of the MX104 router and its
components.
Table 51: Physical Specifications of the MX104 Router Chassis
DepthHeightWidthWeightComponent
9.461 in. (24 cm)6.09 in. (15.47 cm)17.22 in. (43.7 cm)
19.2 in. (48.7 cm) with
mounting brackets
attached
•
Chassis without power
supplies, fan tray, or MICs:
19.56 lb (9 kg)
•
Chassis with power supplies,
fan tray, and MICs: 32 lb
(14.5 kg)
Chassis
8.58 in. (21.8 cm)5.39 in. (13.7 cm)1.48 in. (3.8 cm)1 lb (0.45 kg)Fan tray
7.38 in (18.74 cm)1.9 in. (3.28 cm)6.25 in. (15.9 cm)Maximum up to 1.2 lb (0.54 kg)MIC
8.88 in. (22.55 cm)1.75 in. (4.45 cm)4 in. (10.16 cm)2.5 lb (1.13 kg)AC power supply
8.88 in. (22.55 cm)1.75 in. (4.45 cm)4 in. (10.16 cm)3 lb (1.36 kg)DC power supply
7.25 in. (18.42 cm)0.87 in. (2.2 cm)4.59 in. (11.66 cm)8.9 oz (0.3 kg)Routing Engine
