Table 46: MICs Supported by MX5, MX10, MX40, MX80, and MX104 Routers (continued)
MX104MX80MX40MX10MX5PortsMIC Model NumberMIC Name
13.2R2-----MIC-4COC3-1COC12-CE-HChannelized OC3/STM1
(Multi-Rate) Circuit Emulation
MIC with SFP (H)
Tri-Rate
13.2R210.211.2R411.2R4–40MIC-3D-40GE-TXTri-Rate MIC
Services
13.3R213.2
Rear slot
only.
Supported
on the
modular
MX80 and
fixed
MX80-48T
13.2
Rear
slot
only.
13.2
Rear
slot
only.
13.2
Rear
slot
only.
0MS-MIC-16GMultiservices MIC
SONET/SDH
13.312.212.212.212.21MIC-3D-1OC192-XFPSONET/SDH OC192/STM64 MIC
with XFP
Related
Documentation
MX Series MIC Overview•
• MIC/MPC Compatibility
MX104 Port and Interface Numbering
•
Identifying Interface Numbers on the Hardware on page 53
•
Identifying Interface Numbers in the CLI on page 55
Identifying Interface Numbers on the Hardware
Each MX104 router has three built-in MPCs, which are represented in the CLI as FPC 0
through FPC 2. The numbering of the MPCs is from bottom to top (see
Figure 14 on page 54).
NOTE: The port numbers on MICs correspond to the port numbers on the
interface. The port numbering on the MIC-3D-20GE-SFP-EH MIC depicted
in Figure 14 on page 54 is only one example of the port numbering for MICs.
Each MIC might number ports differently—horizontally or vertically, for
example—and it is important to review the port numbering for your particular
MIC in the MX Series Interface Module Reference.
53Copyright © 2017, Juniper Networks, Inc.
