Installing an MX104 Management Ethernet Cable
To install a serial cable connected to a management device:
1. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the
ESD points on the chassis.
2. Plug one end of the replacement cable into the appropriate ETHERNET port.
3. Plug the other end of the cable into the network device.
Related
Documentation
MX104 Routing Engine Ethernet Port Specifications on page 84•
Replacing an MX104 Fiber-Optic Cable
1.
Disconnecting an MX104 Fiber-Optic Cable on page 139
2.
Connecting an MX104 Fiber-Optic Cable on page 140
Disconnecting an MX104 Fiber-Optic Cable
The MX104 router has field-replaceable unit (FRU) optical transceivers to which you can
connect fiber-optic cables.
Before you begin disconnecting a fiber-optic cable from an optical transceiver installed
in an MX104 router, ensure that you have taken the necessary precautions for safe handling
of lasers (see “Laser Safety Warnings for Juniper Networks Devices” on page 231).
Ensure that you have the following parts and tools available:
•
A rubber safety cap to cover the transceiver
•
A rubber safety cap to cover the fiber-optic cable connector
To disconnect a fiber-optic cable from an optical transceiver installed in the router:
1. Disable the port in which the transceiver is installed by issuing the following command:
[edit interfaces]
user@router# set interface-name disable
WARNING: Do not look directly into a fiber-optic transceiver or into the
ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables
connected to transceivers emit laser light that can damage your eyes.
2. Carefully unplug the fiber-optic cable connector from the transceiver.
139Copyright © 2017, Juniper Networks, Inc.
Chapter 19: Replacing Chassis Components
