PIC 0 BUILTIN BUILTIN 4x 10GE(LAN) SFP+
Fan Tray 0 REV 02 711-049570 CAAX6564 Fan Tray
Most components also have a small rectangular serial number ID label (see
Figure 64 on page 206) attached to the component body.
Figure 64: Serial Number ID Label
Related
Documentation
MX104 Chassis Serial Number Label on page 206•
• Returning a Hardware Component to Juniper Networks, Inc. on page 209
MX104 Chassis Serial Number Label
The chassis serial number is located on the rear of the chassis (see Figure 65 on page 206).
Figure 65: MX104 Chassis Serial Number Label
Related
Documentation
Displaying MX104 Components and Serial Numbers on page 205•
• Returning a Hardware Component to Juniper Networks, Inc. on page 209
MX104 Fan Tray Serial Number Label
The fan tray serial number is located on the rear of the fan tray (see Figure 66 on page 207).
Copyright © 2017, Juniper Networks, Inc.206
MX104 3D Universal Edge Router Hardware Guide
