Table 47: MX104 MIC Interface Names (continued)
Interface Names
ComponentName in the
CLIComponent
type-0/0/port
type-0/1/port
See MX Series Interface
Module Reference.
MIC 0 (left) installed in MPC 0 (labeled 0/0)
type-0/2/port
type-0/3/port
MIC 1 (right) installed in MPC 0 (labeled 0/1)
type-1/0/port
type-1/1/port
MIC installed in MIC slot 1/0
type-1/2/port
type-1/3/port
MIC installed in MIC slot 1/1
Identifying Interface Numbers in the CLI
In the physical part of the interface name, a hyphen (-) separates the media type from
the MPC number (represented as an FPC in the CLI), and a slash (/) separates the logical
PIC and port numbers:
type-fpc/pic/port
•
type—Media type, which identifies the network device. For example:
•
ge—Gigabit Ethernet interface
•
so—SONET/SDH interface
•
xe—10-Gigabit Ethernet interface
For a complete list of media types, see Interface Naming Overview.
•
fpc—Slot in which the MPC is installed. On the MX104 router, the three MPCs are built
into the chassis and are represented in the CLI as FPC 0, FPC 1, or FPC 2.
•
pic—Logical PIC on the MIC. The number of logical PICs varies depending on the type
of MIC.
•
port—Port number.
NOTE: The MIC number is not included in the interface name.
The following sample CLI output displays the three built-in MPCs and five MICs.
user@host> show chassis hardware
Hardware inventory:
Item Version Part number Serial number Description
Chassis G3498 MX104
