DC-powered models—See “Connecting DC Power Cables to the MX104 Router” on
page 117.
8. Perform initial configuration of the router by following instructions in “Initially
Configuring the MX104 Router” on page 129.
Related
Documentation
MX104 3D Universal Edge Router Overview on page 3•
Installing the MX104 Router in the Rack
NOTE: The router can be installed horizontally in a rack or cabinet.
To install the router in the rack (see Figure 25 on page 111):
CAUTION: Before front mounting the router in a rack, have a qualified
technician verify that the rack is strong enough to support the router'sweight
and is adequately supported at the installation site.
NOTE: One person must be available to lift the router while another secures
it to the rack.
CAUTION: If you are mounting multiple units on a rack, mount the heaviest
unit at the bottom of the rack and mount the other units from the bottom of
the rack to the top in decreasing order of the weight of the units.
1. Ensure that the rack is in its permanent location and is secured to the building. Ensure
that the installation site allows adequate clearance for both airflow and maintenance.
2. Position the router in front of the rack or cabinet.
3. Hold onto the bottom of the chassis and carefully lift it so that the mounting brackets
contact the rack rails.
WARNING: To prevent injury, keep your back straight and lift with your
legs, not your back. Avoid twisting your body as you lift. Balance the load
evenly and be sure that your footing is solid.
4. Align the mounting brackets with the holes in the rack rails.
Copyright © 2017, Juniper Networks, Inc.110
MX104 3D Universal Edge Router Hardware Guide
