CHAPTER 2
Chassis Components and Descriptions
•
SRX1500 Services Gateway Chassis Overview on page 5
•
Understanding the SRX1500 Services Gateway Front Panel on page 5
•
Understanding the SRX1500 Services Gateway Back Panel on page 8
SRX1500 Services Gateway Chassis Overview
The SRX1500 Services Gateway chassis is a rigid sheet metal structure that houses all
the other hardware components. The chassis weighs 15 lb. and measures 1.75 in. high,
17.5 in. wide, and 18.2 in. deep. The chassis installs in standard 600-mm deep (or larger)
enclosed cabinets or 19-in. equipment racks.
CAUTION: Beforeremoving or installingcomponentsofa functioning services
gateway, attach an electrostatic discharge (ESD) strap to an ESD point and
place the other end of the strap around your bare wrist. Failure to use an ESD
strap could result in damage to the device.
The services gateway must be connected to earth ground during normal operation. The
protective earthing terminal on the rear of the chassis is provided to connect the services
gateway to ground. Additional grounding is provided to an AC-powered services gateway
when you plug its power supply into a grounded AC power receptacle.
Related
Documentation
SRX1500 Services Gateway Overview on page 3•
• Understanding the SRX1500 Services Gateway Front Panel on page 5
• Understanding the SRX1500 Services Gateway Back Panel on page 8
Understanding the SRX1500 Services Gateway Front Panel
Figure 1 on page 6 shows the front panel of the SRX1500 Services Gateway. The front
panel contains LEDs, Power and Reset Config buttons, and various ports.
5Copyright © 2017, Juniper Networks, Inc.
