SRX1500 Services Gateway Rack Requirements
When installing the services gateway in a rack, you must ensure that the rack complies
with a 1U (19 in. or 48.7 cm) rack as defined in Cabinets, Racks, Panels, and Associated
Equipment (document number EIA-310-D), published by the Electronic Industries Alliance
(http://www.ecaus.org/eia/site/index.html).
When selecting a rack, ensure that the physical characteristics of the rack comply with
the following specifications:
•
The outer edges of the mounting brackets extend the width of the chassis to 19 in.
(48.7 cm).
•
The front of the chassis extends approximately 0.5 in. (1.27 cm) beyond the mounting
ears.
Related
Documentation
SRX1500 Services Gateway Spacing of Mounting Brackets and Flange Holes on page 25•
• SRX1500 Services Gateway Clearance Requirements for Airflow and Hardware
Maintenance on page 26
• SRX1500 Services Gateway Rack-Mounting Requirements and Warnings on page 21
SRX1500 Services Gateway Spacing of Mounting Brackets and Flange Holes
The spacing of the mounting brackets and flange holes on the rack and device mounting
brackets are as follows:
•
The holes within each rack set are spaced at 1U (1.75 in. or 4.5 cm).
•
The mounting brackets and front-mount flanges used to attach the chassis to a rack
are designed to fasten to holes spaced at rack distances of 1U (1.75 in.).
•
The mounting holes in the mounting brackets provided with the device chassis are
spaced 1.25 in. (3.2 cm) apart, measured from the center of each hole.
Related
Documentation
SRX1500 Services Gateway Rack-Mounting Requirements and Warnings on page 21•
• SRX1500 Services Gateway Rack Requirements on page 25
• SRX1500 Services Gateway Clearance Requirements for Airflow and Hardware
Maintenance on page 26
25Copyright © 2017, Juniper Networks, Inc.
