NOTE: By design, the mini-USB console port hashigher priority over the RJ-45
console port. If both mini-USB and RJ-45 console ports are connected, then
the mini-USB console port will be active.
Table 18: Mini-USB Type-B Connector Pinouts for the Services Gateway
Console Port
DescriptionCable ColorSignalPin
+5 VDCRedVCC1
Data -WhiteD-2
Data +GreenD+3
Could be not
connected (N/C),
connected to ground
(GND), or used as an
attached device
presence indicator
N/CX
GroundBlackGND4
Related
Documentation
• RJ-45 Connector Pinouts for the SRX1500 Services Gateway Console Port on page 38
• RJ-45 Connector Pinouts for the SRX1500 Services Gateway Ethernet Port on page 37
• Understanding the SRX1500 Services Gateway Front Panel on page 5
• SRX1500 Services Gateway Installation Overview on page 43
