• Understanding the SRX1500 Services Gateway Front Panel on page 5
• SRX1500 Services Gateway Installation Overview on page 43
RJ-45 Connector Pinouts for the SRX1500 Services Gateway Console Port
The SRX1500 Services Gateway has two console ports: an RJ-45 Ethernet port and a
mini-USB Type-B port. The port on the front panel labeled CONSOLE is an asynchronous
serial interface that accepts an RJ-45 connector. Table 17 on page 38 describes the RJ-45
connector pinouts for the console port.
Table 17: RJ-45 Connector Pinouts for the Services Gateway Console Port
DescriptionSignalPin
Request to SendRTS1
Data Terminal ReadyDTR2
Transmit DataTXD3
Signal GroundGround4
Signal GroundGround5
Receive DataRXD6
Data Set ReadyDSR/DCD7
Clear to SendCTS8
Related
Documentation
Mini-USB Connector Pinouts for the SRX1500 Services Gateway Console Port on
page 38
•
• RJ-45 Connector Pinouts for the SRX1500 Services Gateway Ethernet Port on page 37
• Understanding the SRX1500 Services Gateway Front Panel on page 5
• SRX1500 Services Gateway Installation Overview on page 43
Mini-USB Connector Pinouts for the SRX1500 Services Gateway Console Port
The SRX1500 Services Gateway has two console ports: an RJ-45 Ethernet port and a
mini-USB Type-B port. If your management device (laptop or PC) does not have a DB-9
male connector pin or an RJ-45 connector pin, you can connect your management device
to the Mini-USB Type-B console port of the services gateway by using a cable that has
a standard Type-A USB connector on one end and a Mini-USB Type-B (5-pin) connector
on the other end. Table 18 on page 39 describes the Mini-USB Type-B connector pinouts
for the console port.
Copyright © 2017, Juniper Networks, Inc.38
SRX1500 Services Gateway Hardware Guide
