CHAPTER 9
Cable Specifications and Pinouts
•
RJ-45 Connector Pinouts for the SRX1500 Services Gateway Ethernet Port on page 37
•
RJ-45 Connector Pinouts for the SRX1500 Services Gateway Console Port on page 38
•
Mini-USB Connector Pinouts for the SRX1500 Services Gateway Console
Port on page 38
RJ-45 Connector Pinouts for the SRX1500 Services Gateway Ethernet Port
The port on the front panel labeled MGMT is an autosensing 10/100/1000-Mbps Ethernet
RJ-45 receptacle that accepts an Ethernet cable for connecting the services gateway to
a management LAN (or other device that supports out-of-band management).
Table 16 on page 37 describes the RJ-45 connector pinouts for the Ethernet port.
Table 16: RJ-45 Connector Pinouts for Services Gateway Ethernet Port
SignalPin
TX+1
TX-2
RX+3
Termination network4
Termination network5
RX-6
Termination network7
Termination network8
Related
Documentation
RJ-45 Connector Pinouts for the SRX1500 Services Gateway Console Port on page 38•
• Mini-USB Connector Pinouts for the SRX1500 Services Gateway Console Port on
page 38
37Copyright © 2017, Juniper Networks, Inc.
