Figure 5: DC Power Supply for the SRX1500 Services Gateway
CAUTION: Do not mix AC and DC power supplies within the same services
gateway. Damage to the device might occur.
The power supplies produce and distribute different output voltages to the services
gateway components according to their voltage requirements.
Table 6 on page 14 lists the power consumption values for the power supplies.
Table 6: Component Power Output/Consumption
Output/ConsumptionPower Supply
400 W @12 V400 W AC power supply
650 W @12 V650 W DC power supply
Related
Documentation
• SRX1500 Services Gateway AC Power Supply Electrical Specifications on page 33
• Connecting an AC Power Cord to the SRX1500 Services Gateway on page 66
• Powering On the SRX1500 Services Gateway on page 68
• Powering Off the SRX1500 Services Gateway on page 69
