14.Temperaturesensoroffset(t
r0
)
Temperature sensoroffset (t
r0
)canbe adjustedin theSETUP loop. Dependingonthe meter’sconfiguration, this
functioncanbedisabledandthemenuitemwillinthatcasedisplay“Off”.
Offsetcanbeadjustedintheinterval‐0.99…0.99K.Bypressingtheprimarykey,the0andthesignstartflashing,and
it
isnowpossibletotogglebetween–and+,indicatedinthedisplayby thefactthatth eminussignflashesandswitches 
offrespectively.Bypressingthearrowkeys,themetershiftsfocustothefirstdecimal,i.e.itisnotpossibletochange
thevalueofthefirstdigitasthevalidintervalis‐0.99…0.99K.Boththefirstandseconddecimalcanbesettoavalue
between0and9.Readmoreaboutorderdatainparagraph7.3.

Note:Thesetoffsetisactiveforalltemperaturesensorsthatareconnected
toMULTICAL®603,i.e.botht1,t2andt3.


15.Radioon/off
Themeter’sradio/wirelesscommunicationcanbeadjustedtobeingswitchedonorswitchedoff.Themeter
automaticallyturnsontheradiowhenthemeterleavesthetransportstate,i.e.whenthemeterhasregistereda
flowof1
%ofq
p
orlarger.Theradioon/offfunctionintheSETUPloopisprimarilyusedforswitchingontheradioin
transportstate,withoutthemeterhavingregisteredflow,aswellasforswitchingofftheradiowhenthemeteris
dismountedafterhavingbeeninoperation,e.g.Ifthemeteris
tobesentbyairfreight.Themeter’spresentcondition
isindicatedbytwosymbolsinthebottomleftcornerofthedisplay.

Theabovedefinitionoftheradioon/offsymbolssimplifytheuseofradioon/offintheSETUPlooptooasitis
possibletoswitchbetweenradioon/offwhetheramoduleismountedinthemeterornot.Thisprovidesflexibilityas
theutilitycanconfigurethemeterpriortomounting
amoduleandthusensurethatradiobydefaultiseither
switchedonorswitchedoffwhenthemoduleissubsequentlymounted.

Beawareofsettingthere q uired offsetadjustment,nottheerrorofthetem perat uresensorpair.
Iftheselectedtemperaturesensorpaircontributeswithanerrorof‐0.20K,themeter’soffsetmustbeset
at0.20K.
IMPORTANT:
‐Ifthemeter'sradiocommunicationisswitchedoffviatheSETUPloop,themeterwill
subsequentlyswitchontheradiocommunicationagainwhenaflowof1%ofqporlargerhasbeen
registeredforthefirsttime.
‐ Thesymbolsforradioon/offindicatewhetherthemeter
allowsradiocommunication,not
whetheraradiomodulehasactivateditsradiocommunication.Pleasebeawareofthiswhen
troubleshootingthemeter’swirelesscommunication.
