MULTICAL®603

KamstrupA/S∙Technicaldescription∙5512‐2029
_
A1_GB
_
06.2017
81

Ifthereisnotmountedamoduleinthemeter,orifthemountedmoduleisnotaradiomodule,bothsymbolswillbe
turnedoffintheotherloopsofthemeter,regardlessofthesettingofradioon/offintheSETUPloop.MULTICAL®603
alwaysallowsforradiocommunication
duringoperation.
 RadioON RadioOFF Nomodule/notradiomodule
SETUP
loop
 
USER/TECH
loop
 

16.+17.InputsA1andB1(pre‐settingofregisters)
Itis possibleto pre‐setthevaluesofpulseinputs A1andB1 intheSETUPloop sothatthe meter’sdisplay isin
accordancewiththeconnectedwaterand/orelectricitymeters.Theexampleisbasedontheconnection
ofawater
meter.

Note:IfitisrequiredtousethepulseinputsA2andB2,METERTOOLHCWisusedforpre‐settingtheregisters.
18.+19.MeternumbersofinputsA1an dB1
Themeternumbersofthewaterand/orelectricitymeterconnectedtopulseinputsA1
andB1canbeadjustedinthe 
SETUPloop.TheexampleshowsthemeternumberconnectedtopulseinputB1.

Note:IfitisrequiredtousethepulseinputsA2andB2,METERTOOLHCWisusedforsettingthemeternumbers.
20.+21.+22.Tarifflim its(TL2,
TL3andTL4)
Themeter’sthreetarifflimitscanbeadjustedintheSETUPloop.Thetarifflimitsareonlyactiveifatarifftypehas
beenselectedduringconfigurationofthemeter,i.e.theEE‐codediffersfrom“00”.TheEE‐codeisshownintheTECH
loop,see
paragraph6.2.Ifatarifftypehasbeenselected,themenupointsreflectthisbydisplayingthecorrecttariff
limitunits.Ifnotarifftype hasbeenselectedthemenupointswillbewithoutunits.Readmoreabouttarifftypesin
paragraph3.2.5.

Note:Itisnotpossibletohavedifferenttypesoftarifflimits.Thedisplayreadings
shownarejustexamples.

 
