Series 2280 Precision DC Power Supply Reference Manual Section 3: Functions and features
077085503 / March 2019 3-29
If the instrument is controlled remotely, you can configure any of the parameters discussed above. If
you change from remote to local control, the trigger model measurement method remains selected
until you change it. The following table lists the commands related to the trigger model.
SCPI command
Description
:ARM[:SEQuence[n]]:COUNt (on page 7-
19)
Set the number of times to repeat the arm event.
:ARM[:SEQuence[n]]:SOURce (on page
7-20)
Select the control source for the arm layer. The available
control sources are:
 Immediate triggering
 External triggering
 Manual triggering
 Bus triggering
:TRIGger[:SEQuence[n]]:SOURce (on
page 7-151)
Select the control source for the arm layer. The available
control sources are:
 Immediate triggering
 External triggering
 Manual triggering; for details, see the example Perform
a fast current load measurement (on page 5-7)
:TRIGger[:SEQuence[n]]:COUNt (on
page 7-149)
Set the number of times to repeat the trigger event
:TRIGger[:SEQuence[n]]:SAMPle:COUNt
(on page 7-150)
Set the number of measurements per trigger event
:FORCe:TRIGger (on page 7-15)
Bypass the control source (Arm layer or Trigger layer) when
you do not want to wait for the programmed event to occur
:INITiate[n][:IMMediate] (on page 7-52)
Start the trigger model
:INITiate[n]:CONTinuous (on page 7-51)
Enable and disable continuous triggering
:ABORt[n] (on page 7-11)
Stop all trigger model commands on the instrument
For more examples of using the trigger model, refer to Perform a fast current load measurement (on
page 5-7).
