Section 4: Measurement optimization Series 2280 Precision DC Power Supply Reference Manual
4-10 077085503 / March 2019
6. For the Window, select one of the sizes.
7. Select HOME to return to the operating display.
Once the filter type and count are set up, you can enable and disable the averaging filter from the
home screen. On home screen 2, press the Calculate soft key. The Calculate window is displayed.
Press the Filter soft key to enable or disable the filter operation. When the operation is enabled, the
CALC indicator on the home screen is illuminated.
Using SCPI commands
To set number of measurements to be averaged for current measurements:
:SENS:CURR:AVER:COUN <n>
:SENS:CONC:AVER:COUN <n>
:SENS:VOLT:AVER:COUN <n>
Where <n> is the number of measurements to average (2 to 100).
To set filter type to be averaged:
:SENS:CURR:AVER:TCON <type>
:SENS:CONC:AVER:TCON <type>
:SENS:VOLT:AVER:TCON <type>
Where <type> is the filter type MOVing.
To set the filter window size:
:SENS:CURR:AVER:WIND <n>
:SENS:CONC:AVER:WIND <n>
:SENS:VOLT:AVER:WIND <n>
Where <n> is window size (0.01 to 100).
To enable the selected averaging filter:
:SENS:CURR:AVER:STATe ON
:SENS:CONC:AVER:STATe ON
:SENS:VOLT:AVER:STATe ON
